TA-3300 Series Key Switches offer system designers several configuration choices. TA-3300 Series Key Switches are mounted on cast aluminum
plates as standard. Stainless steel plates are available upon request.

Several options are available for the TA-3300 Series including narrow mounting, LED indicators and lettering.

Single Gang Key Switch Selection:
TA-3301   Momentary Action 1x(SPDT)
TA-3302   Momentary Action 1x(DPDT)
TA-3303   Momentary Action 2x(SPDT)
TA-3304   Momentary Action 2x(DPDT)
TA-3305   Alternate Action 1x(SPDT),
                  Momentary Action 1x(SPDT)
TA-3306   Alternate 1x(DPDT),Momentary Action 1x(DPDT)

*Specify LED voltage required when ordering,

-12 or - 24 (VDC)

Key Switch Options:

(-A)                Add for Alternate Action
(-N)                Add for Narrow Plate
(-R)                Add for 1 Red LED
(-G)               Add for 1 Green LED
(-RG)             Add for 1 Red and 1 Green LED
(-B)                Add for 1 Bi-Colour LED, Red/Green
(-BB)             Add for 2 Bi-Colour LED, Red/Green
(-OR)             Add for "Override/Reset" text
(-LK)             Add for "Secure" text and arrow
(-HO)             Add for "Hold Open" text and arrow
